ZKSVD600PRO_RL Carton Rotary Die Cutting Plotter Suction-type Fully Automatic Paper Feeding

Name: ZKSVD600PRORL Carton Rotary Die Cutting Plotter Suctiontype Fully Automatic Paper Feeding
Brand: Anycut
Price: 3280 USD

Quality ZKSVD600PRO_RL Carton Rotary Die Cutting Plotter Suction-type Fully Automatic Paper Feeding for sale

Auto contour cut : Automatically camera contour cutting

Camera positioning accuracy : ±0.1mm

Tool head configuration : Dual independent heads (Cutting + Creasing)

Suitable cutting material : Self-adhesive sticker/coated paper/PVC

Positoning mode : Qr code/Dot/Right angle

Integrated processing capability : Full cut/Half cut/Creasing in one pass

Key Selling Points : Kiss Cut, Perforated Cut, Flex Cut

Max. cutting speed : 1600mm/s

Related Machine Type : Die Cut Machine, Craft Cutter, Label Maker

Support software : CDR/AI/PS/Contour software/Signmaster(optional)

MaxMedia feeding capacity : 1000 Sheets per Batch

Brand Name : Anycut

Model Number : ZKSVD600PRO_RL

Certification : CE/FCC/RoHS

Place of Origin : Anhui

MOQ : 1 piece

Price : $3280-5000/piece

Supply Ability : 1-4 pieces：2days ;5-30 pieces：2-15 days;30-100 pieces:20 days

Delivery Time : 20-30 work days

Packaging Details : Host machine: L 1220mm*W 1220mm*H 780mm; Cabinet: L 1170mm*W 1150mm*H 860mm

Motor : High speed servo motor

Payment Terms : T/T,Western Union

Material compatibility : Corrugated cardboard, PVC, Adhesive Vinyl, Coated paper (up to 600gsm)

Max. cutting width : 600mm

Contact Now

ZKSVD600PRO_RL Carton Rotary Die Cutting Plotter Suction-type Fully Automatic Paper Feeding

The ZKSVD600PRO_RL is an upgraded high-end die-cutting machine , featuring core adsorption wheel indentation and suction-type fully automatic paper feeding technology.

✅ High-Speed Servo Motor & Dual Tool Heads

1600mm/s cutting speed with dual independent heads for cutting and creasing, slashing production time for packaging and labels by 40%.

✅ 1000-Sheet Vacuum Auto-Feeder

Adsorption-style feeder eliminates static and double-feeding issues, enabling non-stop high-volume runs of up to 1000 sheets at once.

✅ All-in-One Cutting & Creasing

Handles full cut, half cut, and creasing in a single pass, ideal for retail packaging, luxury gift boxes, and promotional materials.

✅ AI Camera Contour Cutting

High-precision camera auto-detects registration marks, ensuring ±0.02mm accuracy for intricate shapes like custom hang tags and die-cut labels.

✅ Multi-Connectivity & Offline Operation

Supports WiFi, Ethernet, USB, and U-disk offline use, with direct integration to AI and CorelDRAW for seamless workflow.

✅ Heavy-Duty Versatility

This cutting plotter is 3000g cutting force handles materials up to 600gsm, including corrugated cardboard, PVC, and adhesive vinyl, covering all small business packaging needs.

MODEL	ZKSVD600PRO_RL
Max. media width	650mm
Max. cutting width	600mm
Auto contour cut	Camera (automatically contour cutting)
Control panel	5.0inch touch screen
Motor	High speed servo motor
Positoning mode	Qr code/Dot/Right angle
Number of heads	2
Blade type	Rowland blade
Packing size	Host machine: L 1220mmW 1220mmH 780mm; Cabinet: L 1170mmW 1150mmH 860mm
Machine size	L 1050mmW 1050mmH 1200mm
Gross/Net weight	343kgs/237kgs
Cutting accuracy	+/- 0.01mm
Repeatability	0.082mm
Max.material thickness	600gsm
Max. cutting speed	1600mm/s
Max.force	3000g
Connect or interface	USB cable/Udisk/web cable/WIFI
Power	﹤150w
Working environment	﹢5℃-﹢35℃
Power supply	100v-240v(adaptive)
Suitable cutting material	Self-adhesive sticker/coated paper/PVC
Support software	CDR/AI/PS/Contour software/Signmaster(optional)

ZKSVD600PRO_RL Carton Rotary Die Cutting Plotter Suction-type Fully Automatic Paper Feeding
